            LC4 cascade safety grating


            ·Security level reaches Type 4, PLe.
            ·The protection height is 140mm to 1420mm.
            ·A protection system consisting of a set of main gratings and 1 ~ 3 sets of auxiliary gratings, transmission lines and accessories.
            ·Four sets of gratings can be connected in series, and the total number of beams can reach 288 at most.
            ·Can realize the "serial setting" with increased detection height
            ·Set ",L-shaped setting and U-shaped setting of multi-sided protection.
            ·Pass TUV safety certification

            ▊Directives and standards
            EU directive
            Machinery Safety Directive 2006/42/EC and EMC Directive 2014/30/EUU
            European Standards
            EN 61496-1、EN 61496-2、EN 13849-1、EN 61326-1
            international standard
            IEC 61496-1、IEC 61496-2、ISO 13849-1、IEC 61326-1、ISO 13855
            national standard
            GB/T 19436.1、GB/T 19436.2、GB 4584

            ▊specifications and models
            Main optical grating
            serial number
            model
            Optical axis spacing
            Detection accuracy
            Detection distance
            Grating type
            7
            LC4-10-0480mm-Z
            10
            15
            0-6m
            Main grating
            8
            LC4-10-0520mm-Z
            10
            15
            0-6m
            Main grating
            9
            LC4-10-0560mm-Z
            10
            15
            0-6m
            Main grating
            10
            LC4-10-0600mm-Z
            10
            15
            0-6m
            Main grating
            11
            LC4-10-0640mm-Z
            10
            15
            0-6m
            Main grating
            12
            LC4-10-0680mm-Z
            10
            15
            0-6m
            Main grating
            13
            LC4-10-0720mm-Z
            10
            15
            0-6m
            Main grating
            14
            LC4-10-0760mm-Z
            10
            15
            0-6m
            Main grating
            15
            LC4-10-0800mm-Z
            10
            15
            0-6m
            Main grating
            16
            LC4-20-0240mm-Z
            20
            26
            0-6m
            Main grating
            17
            LC4-20-0280mm-Z
            20
            26
            0-6m
            Main grating
            18
            LC4-20-0320mm-Z
            20
            26
            0-6m
            Main grating
            19
            LC4-20-0360mm-Z
            20
            26
            0-6m
            Main grating
            20
            LC4-20-0400mm-Z
            20
            26
            0-6m
            Main grating
            21
            LC4-20-0440mm-Z
            20
            26
            0-6m
            Main grating
            22
            LC4-20-0480mm-Z
            20
            26
            0-6m
            Main grating
            23
            LC4-20-0520mm-Z
            20
            26
            0-6m
            Main grating
            24
            LC4-20-0560mm-Z
            20
            26
            0-6m
            Main grating
            25
            LC4-20-0600mm-Z
            20
            26
            0-6m
            Main grating
            26
            LC4-20-0640mm-Z
            20
            26
            0-6m
            Main grating
            27
            LC4-20-0680mm-Z
            20
            26
            0-6m
            Main grating
            28
            LC4-20-0720mm-Z
            20
            26
            0-6m
            Main grating
            29
            LC4-20-0760mm-Z
            20
            26
            0-6m
            Main grating
            30
            LC4-20-0800mm-Z
            20
            26
            0-6m
            Main grating
            31
            LC4-20-0840mm-Z
            20
            26
            0-6m
            Main grating
            32
            LC4-20-0880mm-Z
            20
            26
            0-6m
            Main grating
            33
            LC4-20-0920mm-Z
            20
            26
            0-6m
            Main grating
            34
            LC4-20-0960mm-Z
            20
            26
            0-6m
            Main grating
            35
            LC4-20-1000mm-Z
            20
            26
            0-6m
            Main grating
            36
            LC4-20-1040mm-Z
            20
            26
            0-6m
            Main grating
            37
            LC4-20-1080mm-Z
            20
            26
            0-6m
            Main grating
            38
            LC4-20-1120mm-Z
            20
            26
            0-6m
            Main grating
            39
            LC4-20-1160mm-Z
            20
            26
            0-6m
            Main grating
            40
            LC4-20-1200mm-Z
            20
            26
            0-6m
            Main grating
            41
            LC4-20-1240mm-Z
            20
            26
            0-6m
            Main grating
            42
            LC4-20-1280mm-Z
            20
            26
            0-6m
            Main grating
            43
            LC4-20-1320mm-Z
            20
            26
            0-6m
            Main grating
            44
            LC4-20-1360mm-Z
            20
            26
            0-6m
            Main grating
            45
            LC4-20-1400mm-Z
            20
            26
            0-6m
            Main grating
            46
            LC4-20-1440mm-Z
            20
            26
            0-6m
            Main grating
            47
            LC4-20-1480mm-Z
            20
            26
            0-6m
            Main grating
            48
            LC4-20-1520mm-Z
            20
            26
            0-6m
            Main grating
            Sub-grating
            serial number
            model
            Optical axis spacing
            Detection accuracy
            Detection distance
            Grating type
            1
            LC4-10-0260mm-F
            10
            15
            0-6m
            Sub-grating
            2
            LC4-10-0300mm-F
            10
            15
            0-6m
            Sub-grating
            3
            LC4-10-0340mm-F
            10
            15
            0-6m
            Sub-grating
            4
            LC4-10-0380mm-F
            10
            15
            0-6m
            Sub-grating
            5
            LC4-10-0420mm-F
            10
            15
            0-6m
            Sub-grating
            6
            LC4-10-0460mm-F
            10
            15
            0-6m
            Sub-grating
            7
            LC4-10-0500mm-F
            10
            15
            0-6m
            Sub-grating
            8
            LC4-10-0540mm-F
            10
            15
            0-6m
            Sub-grating
            9
            LC4-10-0580mm-F
            10
            15
            0-6m
            Sub-grating
            10
            LC4-10-0620mm-F
            10
            15
            0-6m
            Sub-grating
            11
            LC4-10-0660mm-F
            10
            15
            0-6m
            Sub-grating
            12
            LC4-10-0700mm-F
            10
            15
            0-6m
            Sub-grating
            13
            LC4-10-0740mm-F
            10
            15
            0-6m
            Sub-grating
            14
            LC4-10-0780mm-F
            10
            15
            0-6m
            Sub-grating
            15
            LC4-10-0820mm-F
            10
            15
            0-6m
            Sub-grating
            16
            LC4-20-0250mm-F
            20
            26
            0-6m
            Sub-grating
            17
            LC4-20-0290mm-F
            20
            26
            0-6m
            Sub-grating
            18
            LC4-20-0330mm-F
            20
            26
            0-6m
            Sub-grating
            19
            LC4-20-0370mm-F
            20
            26
            0-6m
            Sub-grating
            20
            LC4-20-0410mm-F
            20
            26
            0-6m
            Sub-grating
            21
            LC4-20-0450mm-F
            20
            26
            0-6m
            Sub-grating
            22
            LC4-20-0490mm-F
            20
            26
            0-6m
            Sub-grating
            23
            LC4-20-0530mm-F
            20
            26
            0-6m
            Sub-grating
            24
            LC4-20-0570mm-F
            20
            26
            0-6m
            Sub-grating
            25
            LC4-20-0610mm-F
            20
            26
            0-6m
            Sub-grating
            26
            LC4-20-0650mm-F
            20
            26
            0-6m
            Sub-grating
            27
            LC4-20-0690mm-F
            20
            26
            0-6m
            Sub-grating
            28
            LC4-20-0730mm-F
            20
            26
            0-6m
            Sub-grating
            29
            LC4-20-0770mm-F
            20
            26
            0-6m
            Sub-grating
            30
            LC4-20-0810mm-F
            20
            26
            0-6m
            Sub-grating
            31
            LC4-20-0850mm-F
            20
            26
            0-6m
            Sub-grating
            32
            LC4-20-0890mm-F
            20
            26
            0-6m
            Sub-grating
            33
            LC4-20-0930mm-F
            20
            26
            0-6m
            Sub-grating
            34
            LC4-20-0970mm-F
            20
            26
            0-6m
            Sub-grating
            35
            LC4-20-1010mm-F
            20
            26
            0-6m
            Sub-grating
            36
            LC4-20-1050mm-F
            20
            26
            0-6m
            Sub-grating
            37
            LC4-20-1090mm-F
            20
            26
            0-6m
            Sub-grating
            38
            LC4-20-1130mm-F
            20
            26
            0-6m
            Sub-grating
            39
            LC4-20-1170mm-F
            20
            26
            0-6m
            Sub-grating
            40
            LC4-20-1210mm-F
            20
            26
            0-6m
            Sub-grating
            41
            LC4-20-1250mm-F
            20
            26
            0-6m
            Sub-grating
            42
            LC4-20-1290mm-F
            20
            26
            0-6m
            Sub-grating
            43
            LC4-20-1330mm-F
            20
            26
            0-6m
            Sub-grating
            44
            LC4-20-1370mm-F
            20
            26
            0-6m
            Sub-grating
            45
            LC4-20-1410mm-F
            20
            26
            0-6m
            Sub-grating
            46
            LC4-20-1450mm-F
            20
            26
            0-6m
            Sub-grating
            47
            LC4-20-1490mm-F
            20
            26
            0-6m
            Sub-grating
            48
            LC4-20-1530mm-F
            20
            26
            0-6m
            Sub-grating
